Hydraulic Lines & Hoses

WALTCO 47.5" HIGH PRESSURE HOSE
• 3/8" JIC Female Swivel (2)

MAXON HOSE & COMM CABLE ASSY

MAXON #8 TUBE END O-RING FACE SEAL

WALTCO SECONDARY PUMP SUCTION LINE
• Approximately 10" OAL

WALTCO 98" HIGH PRESSURE HOSE
• 3/16 Flare x 3/16 Female Swivel

WALTCO 90" HIGH PRESSURE HOSE
• 3/16 JIC Female Swivel (2)

WALTCO 26" HIGH PRESSURE HOSE
• 3/8" JIC Female Swivel (2)

PALFINGER CURBSIDE HYDRAULIC PIPE
• Approximately 42" OAL

MAXON UP-LINE TUBE ASSEMBLY

PALFINGER 90" HIGH PRESSURE HOSE
• 3/8 JIC Female Swivel
• 3/8" JIC Male Flare

PALFINGER SINGLE CYLINDER HOSE KIT

WALTCO 90.5" HIGH PRESSURE HOSE
• 1/2" JIC Flare X 90° 1/2 JIC Female Swivel

WALTCO 18" HIGH PRESSURE HOSE
•  1/4" JIC Female Swivel (2)

MAXON HIGH PRESSURE HYDRAULIC HOSE
• 42.5" Long, 3/8" SAE#8-6 90° Elbow

PALFINGER 55" HIGH PRESSURE HOSE
• 1/4" JIC Female Swivel (2)

MAXON DOWN-LINE TUBE ASSEMBLY

PALFINGER 28" HIGH PRESSURE HOSE
• 1/4" JIC Female Swivel (2)

WALTCO STEEL RETURN LINE
• Approximately 14" OAL

MAXON HIGH PRESSURE HYDRAULIC HOSE
• 102" Long, 3/8" SAE#8-6 90° Elbow

MAXON HIGH PRESSURE HYDRAULIC HOSE
• 36" Long, 3/8" SAE#6-6 90° Elbow

PALFINGER HP HYDRAULIC HOSE KIT
• 2-Open/Close Hoses & Chafe Loom

PALFINGER 79" HIGH PRESSURE HOSE
• 1/4" JIC Female Swivel
• 90° JIC Female Swivel

PALFINGER LOWER LEFT SIDE HYDRAULIC PIPE
• Approximately 30" OAL

PALFINGER MIDDLE LEFT SIDE HYDRAULIC PIPE
• Approximately 28" OAL

PALFINGER TOP RIGHT SIDE HYDRAULIC TUBE
• Approximately 38" OAL

PALFINGER LOWER RIGHT SIDE HYDRAULIC PIPE
• Approximately 43" OAL

PALFINGER 34" HIGH PRESSURE HOSE
• 1/4" JIC Female Swivel (2)

MAXON HIGH PRESSURE HYDRAULIC HOSE
• 95" Long, 3/8" SAE#6-6 90° Elbow

MAXON #6 TUBE END O-RING FACE SEAL
