H83468211
H83468211
Product Status: New
Product Price:
$160.82
In stock
SKU
rs-h83468211
HELLA LED LIGHT HEAD KIT - WHITE
• 12V In-line control unit with two LED concealed lightheads
• Pop-In design for easy installation
• 19 Selectable Flash Patterns
• LEDs rated to 100,000 hours of operation
• Non-volatile memory recalls last flash pattern used at power up
• Multiple units can be sychronized and can flash simultaneously or alternately
• Reverse polartiy protection
• Weatherproof and vibration resistant for external or internal use
• Direct replacement of Xenon strobes
• Flange option for exterior surface mounting
No data available
| LED Element | high intensity LEDs 6LEDs per head |
|---|---|
| Light color | white |
| Warning patterns | 19 flash patterns |
| Operates voltage | 10-16V DC |
| Average power | 12 W (varies with flash pattern) |
| Max power | 23.5 W |
| Function wires | 6’ (185cm) wire leads, 20AWG, 4 wires |
| Connection cable: output | 34” (86cm) / 22AWG |
| Connection cable: extension | 79” (200cm) /22AWG |
| Connection cable: lighthead | 8.2” (21cm) / 22AWG |
| Multi-Unit synchronization | over 15 units |
| Max cable length | controller cable = 20’ (600cm) |
| Max cable length | lighthead cable = 26’ (800cm) |
| Voltage | 12 |
|---|---|
| Manufacturer | Hella |
| Type | LED |
| Mount Type | Hide-Away |
| Color | White |
| Style/Shape | Round |
